Dia 37mm 12v 24V 2nm Brushed Dc Gear Motor 3000 Rpm 180 Rpm 60 Rpm 20W 10W

Product Categories
Wenzhou Tyhe Motor Co., Ltd.
Contact Now

Dia 37mm 12v 24V 2nm Brushed Dc Gear Motor 3000 Rpm 180 Rpm 60 Rpm 20W 10W

Brand Name : TYHE

Model Number : TJZ37RO

Certification : CE/ROHS/ISO9001

Place of Origin : China

MOQ : 500pcs

Price : Negotiation

Payment Terms : T/T, Western Union

Supply Ability : 100000pcs per month

Delivery Time : 15 working days after payment

Packaging Details : Foam wrapped, carton packed

Size : D37mm

Voltage : 3V 6V 12V 24V

Speed : 60rpm or customized

Torque : 2.58N.m

Gear material : Powder metallurgy gear, steel gears

Commutation : Brush brushes

Type : Dc Small Gear Motor, Micro Motor

Keywords : Small Diameter 37mm Gear Box 12v 24 V 3000 Rpm 180 Rpm 60rpm High Torque Low Speed 20 Watt 10w 2nm Brushed Dc Gear Motor

Contact Now

Small Diameter 37mm Gear Box 12v 24 V 3000 Rpm 180 Rpm 60rpm High Torque Low Speed 20 Watt 10w 2nm Brushed Dc Gear Motor

Products Description

Small Diameter 37mm Gear Box 12v 24 V 180 Rpm 60rpm High Torque Low Speed 20 Watt 10w 2nm Brushed Dc Gear Motor

Specifications

DC Motor Technical Data
Model Rated Voltage(V) No-Load Parameters Rated Parameters Stall Parameters
Speed Current Speed Current Torque Output eff Torque Current
rpm mA rpm A mN.m W % mN.m A
ZY3864 12 5000 300 4000 1.10 19.70 8.25 62.51 59.10 6.50
ZY3864 12 6000 380 4800 1.37 20.30 10.20 62.15 60.90 7.98
ZY3864 24 4500 130 3600 0.46 18.20 6.86 62.83 54.60 2.60
ZY3864 24 5000 160 4000 0.55 19.50 8.17 61.88 58.50 3.10
DC Motor With Gearbox Technical Data (0.5M)
Gearbox parameters 12V-5000RPM Input 12V-6000RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
22.5 81 4.6 869.6 6.68 73.40 220.21 1043.5 8.26 75.64 226.91
22.5 81 5.9 678.0 6.68 94.15 282.44 813.6 8.26 97.01 291.04
22.5 73 8.4 476.2 6.0 120.80 362.40 571.43 7.45 124.48 373.44
22.5 73 10.6 377.4 6.0 152.44 457.32 452.83 7.45 157.08 471.24
22.5 73 13.5 296.3 6.0 194.14 582.43 355.56 7.45 200.06 600.17
24.5 65.6 19.3 207.3 5.41 249.42 748.25 248.7 6.69 257.01 771.04
24.5 65.6 24.4 163.9 5.41 315.33 945.98 196.7 6.69 324.93 974.79
24.5 65.6 31.6 126.6 5.41 408.37 1225.12 151.9 6.69 420.81 1262.43
26.5 59 45.0 88.9 4.9 523.04 1569.11 106.67 6.02 538.97 1616.90
26.5 59 57.0 70.2 4.9 662.51 1987.53 84.21 6.02 682.69 2048.07
26.5 59 73.6 54.3 4.9 855.45 2500.00 65.22 6.02 881.51 2500.00
29.5 53 105.0 38.1 4.37 1096.31 2500.00 45.7 5.41 1129.70 2500.00
29.5 53 133.0 30.1 4.37 1388.65 2500.00 36.1 5.41 1430.95 2500.00
29.5 53 172.0 23.3 4.37 1795.85 2500.00 27.9 5.41 1850.55 2500.00
32.5 47.8 245.0 16.3 3.9 2307.07 2500.00 19.59 4.88 2377.33 2500.00
32.5 47.8 310.0 12.9 3.9 2500.00 2500.00 15.48 4.88 2500.00 2500.00
32.5 47.8 401.0 10.0 3.9 2500.00 2500.00 11.97 4.88 2500.00 2500.00
DC Motor With Gearbox Technical Data (0.5M)
Gearbox parameters 24V-4500RPM Input 24V-5000RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
22.5 81 4.6 782.6 5.56 67.81 203.44 869.6 6.62 72.66 217.97
22.5 81 5.9 610.2 5.56 86.98 260.93 678.0 6.62 93.19 279.57
22.5 73 8.4 428.6 5.0 111.60 334.81 476.19 5.96 119.57 358.72
22.5 73 10.6 339.6 5.0 140.83 422.49 377.36 5.96 150.89 452.67
22.5 73 13.5 266.7 5.0 179.36 538.08 296.30 5.96 192.17 576.52
24.5 65.6 19.3 186.5 4.50 230.43 691.28 207.3 5.36 246.89 740.66
24.5 65.6 24.4 147.5 4.50 291.32 873.95 163.9 5.36 312.12 936.37
24.5 65.6 31.6 113.9 4.50 377.28 1131.84 126.6 5.36 404.23 1212.68
26.5 59 45.0 80.0 4.0 483.21 1449.63 88.89 4.82 517.73 1553.18
26.5 59 57.0 63.2 4.0 612.07 1836.20 70.18 4.82 655.79 1967.36
26.5 59 73.6 48.9 4.0 790.32 2370.95 54.35 4.82 846.77 2500.00
29.5 53 105.0 34.3 3.64 1012.83 2500.00 38.1 4.33 1085.18 2500.00
29.5 53 133.0 27.1 3.64 1282.92 2500.00 30.1 4.33 1374.56 2500.00
29.5 53 172.0 20.9 3.64 1659.11 2500.00 23.3 4.33 1777.62 2500.00
32.5 47.8 245.0 14.7 3.3 2131.40 2500.00 16.33 3.90 2283.65 2500.00
32.5 47.8 310.0 11.6 3.3 2500.00 2500.00 12.90 3.90 2500.00 2500.00
32.5 47.8 401.0 9.0 3.3 2500.00 2500.00 9.98 3.90 2500.00 2500.00

2D drawing

Dia 37mm 12v 24V 2nm Brushed Dc Gear Motor 3000 Rpm 180 Rpm 60 Rpm 20W 10W


Dia 37mm 12v 24V 2nm Brushed Dc Gear Motor 3000 Rpm 180 Rpm 60 Rpm 20W 10W

Please let us know your requirements and we will provide you with transmission solutions.

Dia 37mm 12v 24V 2nm Brushed Dc Gear Motor 3000 Rpm 180 Rpm 60 Rpm 20W 10W

Dia 37mm 12v 24V 2nm Brushed Dc Gear Motor 3000 Rpm 180 Rpm 60 Rpm 20W 10W
